Horizontal X-axis

750mm

Longitudinal Y-axis

600mm

Vertical Z-axis

600mm

C-axis

360°

A-axis

-120°~+120°

Distance from spindle end face to worktable

120-720mm

Distance from spindle center to column guide way

650mm

Table size

Φ410mm

Maximum workpiece rotation diameter

620mm

Center hole diameter

70H7mm

Table height (to linear guide way slider surface)

469mm

Maximum load-bearing capacity

200kg

T-slot dimensions

14H7mm

Spindle speed

50-10000rpm

Drive mode

Direct drive

Spindle motor torque (rated/maximum)

52.5/118Nm

Main motor power

11/15kW

X/Y/Z rapid traverse speed

36/36/36m/min

Cutting feed rate

1-10000mm/min

Tool magazine type

ATC tool magazine with 24 tools

Shank specification

BT-40

Positioning accuracy

0.008mm

Repeatability

0.004mm

Machine footprint and height

2900*2400*3000mm

Machine weight (apx.)

8000kg

CNC system

FANUC 0i MF PLUS
